General
| Configuration | Console |
| Warm-up time | 20 seconds |
| First copy speed: B/W | 3.2 seconds |
| Continuous output speed | 80 ppm |
| Memory: standard | 2 GB |
| Memory: maximum | 2 GB |
| HDD: standard | 320 GB |
| HDD: maximum | 320 GB |
| Weight | 200 kg |
| Dimensions: W x D x H | 690 x 883 x 1,161 mm |
| Power source | 220 – 240 V, 50 – 60 Hz |
Copier
| Multiple copying | Up to 9,999 copies |
| Resolution | 600 x 600 dpi |
| Zoom | From 25% to 400% in 1% steps |
Printer
| CPU | Intel® Apollo Lake Processor 1.6 GHz |
| Printer language: standard | PCL5c, PCL6, PostScript 3 (emulation), PDF direct (emulation) |
| Printer language: option | Genuine Adobe® PostScript®3™, IPDS, PDF Direct from Adobe® |
| Print resolution – Maximum: | 1,200 x 1,200 dpi |
| Network interface: standard | Ethernet 10 base-T∕100 base-TX∕1000 base-T, USB Host Type A, USB Device I∕F Type B, Bluetooth, Wireless LAN (IEEE 802.11 b/g/n), USB Host I/F, SD slot, NFC tag, USB Device (TypeB:1Port) |
| Network interface: option | Bi-directional IEEE 1284, Wireless LAN (IEEE 802.11a∕b∕g∕n), RJ45 I/F (Only Copy connect), Ethernet Print only RJ-45 network port |
| Network protocol | TCP/IP (IP v4, IP v6) |
| Windows® environments | Windows® Server 2008R2, Windows® 7/8.1/10, Windows® Server 2008/2012/2012R2/2016, Windows® Server 2019 |
| Mac OS environments | Macintosh OS X v10.12 or later |
| UNIX environments | UNIX Sun® Solaris, HP-UX, SCO OpenServer, RedHat® Linux, IBM® AIX, XenDesktop, Citrix XenApp |
| SAP® environments | SAP® R/3®, SAP® S/4® |
Scanner
| Scanning: B/W | 120 ipm (simplex)/240 ipm (duplex) |
| Scanning: full colour | 120 ipm (simplex)/240 ipm (duplex) |
| Resolution: maximum | 1,200×1,200 dpi |
| Bundled drivers | Network TWAIN |
| Compression method | BW: TIFF (MH, MR, MMR, JBIG2), Grayscale – Colour: JPEG |
| File formats | Single Page TIFF, Single page JPEG, Single page PDF, Single page High compression PDF, Single page PDF∕A, Multi page TIFF, Multi page PDF, Multi page High compression PDF, Multi page PDF∕A |
| Scan modes | E-mail, Folder, USB, SD Card, URL, FTP, SMB |
Fax
| Circuit | PSTN, PBX |
| Compatibility | ITU-T (CCITT) G3 |
| Transmission speed | G3: approximately 2 seconds (200 x 100 dpi, JBIG, ITUT #1 chart TTI off, memory transmission), G3: approximately 3 seconds (200 x 100 dpi, MMR, ITUT #1 chart TTI off, memory transmission) |
| Modem speed: maximum | Kbps |
| Resolution | Standard mode: 8 x 3.85 line⁄mm, 200 x 100 dpi, Detail mode: 8 x 7.7 line⁄mm, 200 x 200 dpi, Super fine mode: 8 x 15.4 line⁄mm, 16 x 15.4 line⁄mm, 400 x 400 dpi (with optional SAF memory) |
| Compression method | MH, MR, MMR, JBIG |
| Page memory size | Standard: 8 MB, With optional SAF memory: 16 MB |
| SAF memory size | Standard: 4 MB (approximately 320 pages), Optional: 60 MB (approximately 4,800 pages) |
| Memory backup | 1 hour(s) |
Paper Handling
| Recommended paper size | A3, A4, A5, A6, B4, B5, B6 |
| Paper input: standard | 4,300 sheets |
| Paper input: bypass (standard) | 100 sheets |
| Paper input: maximum | 8,700 sheets |
| Paper output: standard | 500 sheets |
| Paper output: max. | 3,500 sheets |
| Paper weight – Trays | 52 – 256 g̸ m² |
| Paper weight – Bypass | 52 – 300 g̸ m² |
| Paper weight – Duplex | 64 – 256 g̸ m² |
Ecology
| Power consumption: max. | < 1,900 W |
| Power consumption: sleep | 0.6 W |
| TEC* | 1.696 kWh⁄week |
CONSUMABLES
| Toner (black) | 43,000 prints |
